Vacuum Cup Fittings Flexible Joint MLK Stainless Steel Materials

1. Introduction:

• Corrosion resistance: stainless steel joints are adopted at both ends, which has good corrosion resistance. The tightness is ensured.
• High pressure resistance: taking into account the actual working pressure, working environment and working conditions of metal soft joints, all parameters have been carefully calculated and tested repeatedly to ensure their pressure-bearing safety in work.

2. Application:

• Connect large suction cups for workpieces with inclined surfaces.
• The flexible joint can be used in combination with the spring buffer strut to compensate and adjust the height difference and uneven surface of the workpiece, and can be automatically reset.

3. Technology Data:

***Note: MLK IG(internal thread) AG(external thread)

4. Design Data

Type	Size(MM)
	DN	G1	G2	H	LG1	LG2	SW1	W(°)
MLK G1/4-IG G1/4-AG	3	G1/4''-F	G1/4''-M	27	12	12	17	12
MLK G1/2-IG G1/2-AG	6	G1/2''-F	G1/2''-M	33.5	14	14	27	12

Flexible joint MLK.pdf
